Made from BK7 material, which has transparent range from 330-2100nm. The refractive index is 1.5168 at 587.6nm. The BK7 window has good performance over visible and near IR spectrum for most application.
Achromatic Waveplate Achromatic Waveplates(Retarders), AWP is composed of one piece of Crystal Quartz and one piece of Magnesium Fluoride, MgF2.
Barium fluoride (BaF2) shows good optical transmission over UV-IR windows in 0.15μm~12.5μm.
MgF2 windows are used in the UV, visible and IR ranges, with approximately 94% transmission from 200 - 1000 nm, and approximately 95% transmission from 1-6µm
CaF2 has transparent range from 170-7800nm. The refractive index is 1.399 at 5000nm. 1. Low absorption coefficient 2. High damage threshold, 3. Low Dispersion (with an Abbe Number of 95) 4. Low fluorescence 5. Excellent water, chemical, and heat resistance
product orgin:
Chinashipping port:
Fuzhou Chinapayment:
T/T Payment, Western UnionKDP&DKDP Nonlinear Crystal
Potassium Dihydrogen Phosphate (KDP) (KH2PO4), Potassium Dideuterium Phosphate (DKDP ) (KD2PO4) are among the most widely-used commercial NLO materials, characterized by good UV transmission, high damage threshold, and high birefringence, though their NLO coefficients are relatively low. They are usually used for doubling, tripling and quadrupling of a Nd:YAG laser at the room temperature. In addition, they are also excellent electro-optic crystals with high electro-optic coefficients, widely used as electro-optical modulators, such as Q-switches, Pockels Cells, etc.
KDP&DKDP Crystal Advantages
1.Good UV transmission
2. High optical damage threshold
3. High birefringence High nonlinear coefficients
SPECIFICATIONS:
Width x Length:
1x1 ~ 16x16mm
Lenght:
0.02 ~ 20mm
Dimensional Tolerance:
(W±0.1mm) x (H±0.1mm) x (L+0.2mm/-0.1mm)
Flatness:
<λ/8 at 633nm
Surface Quality:
20/10 Scracth/Dig
Parallelism:
< 20 arc seconds
Perpendicularity:
< 5 arc minutes
Wavefront Distortion:
<λ/8 at 633nm
Clear Aperture:
Central 95%
Chamfer:
0.15x45°
NOTE:
KDP and DKDP surface easier moistens, the user is advised to provide a dry condition (<50%) and the sealed housing for preservation.
Hastings triplets achromatic lenses are designed to provide an infinite conjugate ratio and are useful for focusing collimated beams and for magnification. Steinheil triplets achromatic lenses are designed to provide a finite conjugate ratio and 1:1 imaging.
30° - 60° - 90° Littrow Prisms have two main applications. 1. Uncoated littrow dipersion prisms are used to disperse light into its component spectrum. 2. Coated littrow dipersion prisms are used to deviate the line of sight by 60°.
Optics Glass Micro Lenses Optics Glass micro lenses size are smaller than 3mm, which use for fibter, medical and laser etc. speciification. The shape could be achromatc lenses, plano-convex, meniscus etc. as micro lenses
Optical Aluminum Coated Mirrors Average Reflectance >88% from 450 nm to 10 µm Shape could be customized: Round, Square, Elliptical, Right angle prisms Material could be customized: Fused silica, Pyrex, N-BK7
Germanium Windows are applied for IR Wavelength 1. 3 - 5μm for mid-infrared applications 2. 3 - 12μm for broadband multispectral applications 3. 8 - 12μm for thermal imaging applications
Double Convex Lenses, Bi-convex Lenses have two outward curved surfaces, a positive focal length and are useful for 1:1 imaging and in multi-element systems.These lenses are designed to have a focal length of f= (R1*R2)/((n-1)*(R2-R1)) 1. Supported by the Zemax Optical Design Package 2. Posistive Focal Length 3. Material upon requirement
