Nd:YVO4 Crystal

LOADING IMAGES

High Precision Nd:YVO4 Laser Crystal

Yttrium Vanadate (Nd:YVO4) is one of the most efficient laser host crystal currently existing for diode laser-pumped solid-state lasers.


  • product orgin:

    China
  • shipping port:

    Fuzhou China
  • payment:

    T/T Payment, Western Union
inquiry now
features

High Precision Nd:YVO4 Laser Crystal


Yttrium Vanadate (Nd:YVO4) is one of the most efficient laser host crystal currently existing for diode laser-pumped solid-state lasers. Recent developments have shown that Nd:YVO4 can produce powerful and stable IR, green, bule lasers with the design of Nd:YVO4 and frequency doubling crystals.


Nd:YVO4 Crystal Advantages:

1. Large stimulated emission cross-section at lasing wavelength
2. High absorption coefficient and wide absorption bandwidth at pump wavelength
3. High laser induced damage threshold
4. Good physical, optical and mechanical properties

Nd:YVO4 Crystal Applications:

1. For Single-longitudinal-mode output and compact design
2. Diode laser-pumped Nd:YVO4 compact laser and its frequency-doubled green, red or blue laser will be the ideal laser tools of machining, material processing, spectroscopy, wafer inspection, light show, medical diagnostics, laser printing and other most widespread applications

Nd:YVO4 Crystal


Nd:YVO4 Crystal SPECIFICATION:

Nd dopant: 0.27%, 0.3%, 0.4%, 0.5%, 0.7%, 1.0%, 2.0%, 3.0%
Width x Height: 1x1 ~ 16x15mm
Length: 0.02 ~ 20mm
Optical Axis Orientation: a-cut (+/-0.5°)
Dimension Tolerance Commercial(±0.1mm);High Precision(±0.005mm)
Surface Quality 20/10 Scracth/Dig
Parallelism <30"
Perpendicularity: < 5 arc minutes
Chamfer 0.15×45°
Flatness <λ/8 @633nm
Wavefront Distortion <λ/8 @633nm
Coating 1.AR@1064nm R<0.1%
2.AR@1064nm R< 0.1% & HT@808nm T>95%
3.HR@1064nm R>99.8% & HR@532nm R>99% & HT@808nm T>95%
